Product image slideshow Items
Verfügbar im Shop
Schließen| Modell | GSD S10 |
| Farbe | Gelb |
| Spezial-Farbe | School Bus Yellow/Dark Grey |
| Grösse | One size |
| Material/Werkstoff | 6061-Aluminium |
| Einsatzbereich | Cargo, Kindertransport Urban |
| Geschlecht | uni sex |
| Dimension | Faltmass: 185 x 46 x 88 cm |
| Gänge | 10 |
| Innenlager | Motor integrated |
| Rahmen | Tern GSD, 6061-AL, patented MultiTruss design, DIN 79010 certified: 210 kg |
| Gabel | Suntour custom for Tern, 1.5" tapered Chromoly steerer, 34 mm stanchions, Thru-axle, DIN 79010 certified: 210 kg |
| Radgrösse | 20" |
| Radsatz | Tern Atlas, heavy duty cargo wheel |
| Kurbelgarnitur | Tern GSD, forged 6061-AL DH crankarm |
| Schaltwerk | Shimano Deore Shadow+ |
| Umwerfer | n/a |
| Schalthebel | Shimano Deore, 1 x 10 spd |
| Kassette | Shimano 11-42T, 10 spd |
| Kette | KMC 10 spd, for eBike, EPT corrosion resistant coating |
| Power | 85 Nm |
| Bremse | Magura MT-C ABS, 4-piston hydraulic disc, 203 mm rotor |
| Bremsscheiben | 203mm |
| Kettenführung/Kettenschutz | Tern GSD, full chain cover |
| Vorbau | Tern Andros, adjustable, forged construction, patented technology |
| Lenker | Tern Sweep, 6061-AL, Tern Andros adapted |
| Steuersatz | Tern Flux Pro Taper by FSA, 1.5", angular contact bearings, Physis integrated |
| Sattelstütze | Tern VLT (Very Large Telescope) with Cane Creek suspension and LightAction levers |
| Sattel | Tern GSD by Velo |
| Bereifung | Schwalbe Pick-Up, cargo-optimized, Super Defense puncture protection, Reflex |
| Vorderradnabe | Tern Atlas, Cooling Fins, Boost Thru-Axle, sealed cartridge bearings |
| Hinterradnabe | Tern Atlas, Cooling Fins, Boost Thru-Axle, Syntace X-12 standard |
| Pedalen | Urban with non-slip surface, sealed bearings |
| Schutzblech | F: Aluminum R: GSD wheel guard |
| Ebike | true |
| Gepäckträger | Atlas G, 100 kg capacity |
| Seitenständer | Atlas Lockstand Gen 2, AutoLock w/ remote unlock |
| Frontlicht | Ignis Headlight, Hi/Lo beams, 700 lumens, |
| Rücklicht | RearStop Brake Light, Always on |
| Dynamo | n/a |
| Typ | Longtail Cargo E-Bike |
| Schloss | AXA, keyed-alike with Bosch battery |
| Motor | Bosch Cargo Line, Smart System 400% Assist, max speed 25 km/h |
| Batterie | Bosch PowerPack 545Wh |
| Max. Systemgewicht | 210.00 Kilogramm |
| Felge | Tern Atlas, ultra wide 36 mm, dual reinforced joint |
| Griffe/Lenkerband | Ergon |
| Brand Schaltung | Shimano Wechsel |
